信息技術產品安規測試項目及檢測設備
發表時間:2022-01-06 14:13:41


IEC60950，EN60950標準涉及的檢測項目如下：

1.1 電源接口

1.2 標記和說明

1.3 電擊和能量危險的防護

1.4 SELV電路

1.5 TNV電路

1.6 限流電路

1.7 受限制電源

1.8 接地和連接保護措施

1.9 一次電路過保護和和接地故障保護

1.10 安全聯鎖裝置

1.11 電氣絕緣

1.12 電氣間隙、爬電距離和絕緣穿透距離

1.13 導體的端接

1.14 與電網電源的連接

1.15 連接外部導線的接線端子

1.16 與電網電源的斷開

1.17 設備的互連

1.18 穩定性

1.19 機械強度

1.20 結構設計

1.21 危險的運動部件的防護

1.22 發熱要求

1.23 外殼的開孔

1.24 防火

1.25 接觸電流和保護導體電流

1.26 抗電強度

1.27 異常工作和故障條件

1.28 對通信網絡的維修人員和連接到通信網絡的其他設備的使用人員遭受設備危險的防護

1.29 對設備使用人員遭受來自通信網絡上過電壓的防護

1.30 通信配線系統的過熱保護


Delta德爾塔儀器專業致力于電子電器安全安規性能及非標定制類檢測設備系列的研發和制造，產品應用于各種家用電器（IEC/EN 60335系列, GB4706.1系列，UL60335系列）；信息技術類設備（IEC/EN60950-1, UL60950， GB4943.1），音頻/視頻及類似設備（IEC/EN60065, GB8898，UL60065）；燈具（IEC/EN 60598系列 GB7000.1系列，UL1598）；燈的控制器（整流器）（IEC/EN 61347系列, GB 19510系列，UL8750）；醫用電器設備（IEC/EN 60601系列，GB 9706.1系列，UL1993）進行功率測試，電氣強度測試，發熱試驗，絕緣電阻測試，泄漏電流測試，標簽測試，沖擊測試，電源線測試，扭力測試，推拉力測試，電氣連接和機械固定，防電擊保護測試，爬電距離和電氣間隙，防火阻燃測試，放電測試，保護裝置測試，穩定性測試，可接觸性測試，開關測試，異常操作和故障條件測試，潮濕處理，接地電阻測試，外殼防護測試等測試項目的檢測設備的提供。


IEC60950-1&GB4943.1信息技術類設備檢測實驗室儀器設備推薦清單：


    SAR 測試



手機性能測試



EMC暗室測試


序號條款號檢測內容所需檢測  儀器設備精度要求和量程要求                                          所需檢測儀器、設備
設備名稱  設備型號設備量程設備精度
31.6.2Input   CurrentAmp-meter
數字功率計 WT3100—500V      0—20A       0—10kW ±1.5%
42.1.1.1Access to energized partsTest finger (joint /rigid 30N, fig. 2A)See fig. 2A關節試驗指 GS-IP100fig.   2Afig.   2A
5直型試驗指GS-IP11fig.   2Afig.   2A
6
推拉力計ANF-500—50N±1N
7Test   pin (fig. 2B 4mm/3mm/15 mm long)See   fig. 2B試驗銷 GS-IP03fig.   2Bfig.   2B
8Test   probe (fig. 2C 12mm/80mm)See   fig. 2C 試驗探頭 GS-IP05fig.   2Cfig.   2C
92.1.1.5Energy   HazardVariable   resistive load
電子負載 3250AC/DC       0-60V       0-20A       0-300W±1.5%
102.1.1.7Plug dischargeMeasuring instrument with input impedance 100MΩ   ±5 MΩ in parallel with an input capacitance of 25pF or less.
示波器F196C2mV-100V/div   5ns-5s/div 100M±0.2%
11
高壓探棒N2771A0-10kV±1%
122.1.1.9Audio AmplifiersSuitable signal generator and audio power   measuring equipment
噪聲信號發生器 DF168120-20kHz     0-70dB±1dB
13
音頻信號發生器   GAG-81010-1000kHz±1.5%
142.3.1Limits   of TNV circuitsResistor   5000Ω ± 2%,±2%試樣電阻 5kΩ5000Ω±0.3%
152.3.4Connection   of TNV circuits to other circuitsResistor   5000Ω ± 2%,±2%試樣電阻 5kΩ5000Ω±0.3%
162.3.5Test   for operating voltages generated externallyTest   generator 120V±   2V a.c., 50 or 60 Hz, 1200Ω ± 2%試驗電壓發生器   GS-TNV100-240V      50 or 60 Hz  1200Ω±1%
172.4.2Limited current circuits, limit valuesResistor   2 000 Ω ± 10%, ±   10%試樣電阻 2kΩ2000Ω±0.5%
18Capacitance   measuring device
LCR測量儀4263B10μH-1H   1pF-1μF    0.1Ω-100kΩ±0.1%
192.6.3.4Resistance of   earthing conductorsHigh   current source with a voltage not exceeding 12 V
接地電阻測試儀TOS62100—0.2Ω±0.002Ω
202.9.2Humidity   conditioningChamber   (91% Rh...95% Rh, 20...30 ° C)
調溫（調濕）箱GS-TH800-40—150℃   0-95%RH±2℃，±2.5%RH
212.10Creepage   distance/clearance/distance through insulation (determination of   requirements; working voltage measurements)Oscilloscope
示波器F196C2mV-100V/div   5ns-5s/div 100M±0.2%
22Creepagedistance/clearance/distance through   insulation (measurements)Dial   gauge
爬電距離測試卡CC-231.0—8.0mm0.1mm
23Micrometer
游標卡尺150mm0—150mm0.02mm
24Microscope
讀數顯微鏡Vibao0-100mm±0.05mm
252.10.3.9Measurement of transient levelsTest-generator; reference 2 of table N.1
脈沖發生器1950S脈沖波形：1.2×50μs電壓：0-7KV±5%
26
脈沖發生器1950S脈沖波形：10×700μs電壓：0-7KV±5%
272.10.4Creepage   distancesTest   equipment for tracking
漏電起痕試驗裝置  GS-TK200-600V  0-1A±1%
292.10.9 &   2.10.10 & 2.10.11 (and 2.10.8.2)Thermal   cycling and thermal ageingFull   draught oven (± 2oC)
    Cooling facility (0o C)		±   2oC調溫（調濕）箱GS-TH800-40—150℃   0-95%RH±2℃，±2.5%RH
302.10.8.4Abrasion resistance testScratch test device with steel pin20mm/s;   10±0.5N, 80~85°耐劃痕試驗儀GS-NH30020mm/s;10±0.5N, 80~85°±2%
31頂角40度，倒圓半徑0.25mm±0.02mm鋼針\頂角40度，倒圓半徑0.25mm±0.02mm±1degree，±0.02mm
322.10.7Enclosed   and sealed partsSee   2.10.9 & 2.10.10±   2oC調溫（調濕）箱SETH-Z-061LKGS-TH800-40—150℃   0-95%RH±2℃，±2.5%RH
333.1.5, 3.1.9 and   4.2.210   N steady force testSuitable   tool for applying steady force of 10 N +/- 1N±1N推拉力計ANF-500—50N±1N
353.2.6Cord   anchorage and strain reliefAppropriate   weights
電源線拉扭試驗機GS-DXLN200-50kg±1%
363.2.8Cord   guardsAppropriate   weights
推拉力計ANF-500—50N±1N
374.1StabilityInclined   plane 10°
傾斜平臺GS-QX8000-15o±3%
38Force   250N
推拉力計ZP-10000-1000N±0.2%
39Test tool 800N with a flat surface 12,5cm by   20cm
推拉力計ZP-10000-1000N±0.2%
40金屬平面13612,5cm   by 20cm±0.5%
414.2.3Steady force test 30 NTest finger (rigid 30N± 3N, fig. 2A)
直型試驗指GS-IP11fig.   2Afig.   2A
42推拉力計ANF-500—50N±1N
434.2.4Steady state force, 250 NTest tool 250N± 10N with a circular plan surface   ? 30mm.
推拉力計ZP-10000-1000N±0.2%
44金屬平面GS16?   30mm±0.1mm
454.2.5Impact   test?   50mm/500g± 25g steel ball500g±   25g沖擊鋼球GS-IP07500g         ? 50mm+10g，+0.004mm
464.2.6Drop   testHard   wood 13mm on 19mm to 20mm plywood, two layers
跌落平臺GS207//
474.2.7Stress   reliefOven   70K over normal temp
高溫試驗箱GS-GW005室溫—200℃±1℃
494.2.10Wall   or ceiling mounted equipmentSeveral   weights
推拉力計ZP-10000-1000N±0.2%
504.3.2Handles   and manual controlsForce   15N/20N/30N/50N
推拉力計ANF-500—50N±1N
514.3.6Direct   plug-in equipmentTest   equipment (see Fig. 11 of IEC 60065)
插頭力矩測試儀    GS-CTN040-0.25Nm±1%
534.3.13.2Ionizing   radiationIonization   meter (Annex H)
電離輻射計440RF/D0-1000μSV/h±20%
574.4Protection against hazardous moving partsTest finger (joint /rigid 30N, fig. 2A)See fig. 2A關節試驗指 GS-IP100fig.   2Afig.   2A
58直型試驗指GS-IP11fig.   2Afig.   2A
59
推拉力計ANF-500—50N±1N
604.5Thermal   requirements





61Voltage supplySingle   phase voltage supply systems/variability/adequacy
變頻電源 69020-300V      0-15A±1.5%
62Three   phase voltage supply systems
變頻電源 AFR-36060kVa±1.5%
63Temperature (rise)Temperature   recorder (multi-channel)
記錄儀DR232-02-00-1R0—300℃±0.5℃
64Thermocouples
熱電偶  TT-K-300—150℃±0.5℃
65Winding   resistance (normally > 1,0 Ω 2-wire, 4-wire<1,0 Ω ).
數字多用表34401A0.1-100MΩ±3%
66VoltageVoltmeters   (ac/dc)
數字多用表34401A0—1000V±1%
67High   voltage meter (probe)
高壓探棒N2771A0-10kV±1%
68CurrentCurrents   (ac/dc)
數字功率計 WT3100—500V      0—20A       0—10kW ±1.5%
69LoadingLoads   (resistive)
電子負載 3250AC/DC       0-60V       0-20A       0-300W±1.5%
704.5.5Resistance to abnormal heatBall pressure test apparatus according to IEC   60695-10-2 Oven at least 125oC球直徑：5mm；砝碼：20N±0.2N球壓試驗裝置GS-QY21球直徑：5mm；砝碼：20N±0.2N
71
高溫試驗箱GS-GW005室溫—200℃±1℃
724.6.2Bottoms   of fire enclosureDistillate   fuel oil as described in Annex A.3.210ml   1ml/s灼熱燃油GS-ZRY0610ml     1ml/s±0.2ml   ±0.1ml/s
734.6.4.2Evaluation   of larger openingsSuitable   tool (or tools) to simulate a straight metal object, 1mm in diameter, length   up to 13 mm?   1mm試驗探針GS-IP14?   1mm+0.044mm
744.6.5Adhesives   for constructional purposesOven   up to 100 ° C
高溫試驗箱GS-GW005室溫—200℃±1℃
754.7.3Materials, Tests see Annex AV-1,   V-2, HF-2, 5VIEC60695針焰試驗儀GS-NF30IEC60695IEC60695
76Bunsen   burner (9,5 ± 0,5 mm)IEC60695UL94水平垂直燃燒試驗儀GS-HVUL20IEC60695IEC60695
77Gas   for burner (~37 MJ/m3)
甲烷氣體98%純度以上//
78Oven   for preconditioning
高溫試驗箱GS-GW005室溫—200℃±1℃
794.7.3.6Materials   used in high-voltage componentsTest   of Annex A or test of 14.4 of IEC 60065 or needle flame test according to IEC   60695-2-2IEC60695針焰試驗儀/水平垂直燃燒儀GS-NF30\GS-HVUL20IEC60695IEC60695
805.1Touch   current and protective conductor currentMeasuring   instruments of Annex D
泄漏電流測試儀    Simpson2280-10mA±1%
815.2Electric   strengthTest   equipment with the relevant voltage and tripping current短路電流>200mAAC/DC耐壓絕緣測試儀TOS9201AC:0-5kV，       0—110mA; DC:0-6kV,        0-10mA;         短路電流>200mA±1%
836.2.1Protection   of equipment users from overvoltages on telecommunication networksTest   probe (Fig. 2C, 12mm/80mm)See   fig. 2C 試驗探頭 GS-IP05fig.   2Cfig.   2C
846.2.2.1Impulse   TestImpulse   test generator according to Annex N
脈沖發生器1950S脈沖波形：10×700μs電壓：0-7KV±5%
856.2.2.3Protection   of equipment users from overvoltages on telecommunication networksinsulation   resistance
絕緣電阻測試儀TOS72000-1000V   0-2000MΩ±0.5%
867.4.2Voltage   surge testTest   generator reference 3 of table N.1
浪涌測試儀SUG10/700G0-10kV±5%
877.4.3Impulse   testTest   generator reference 1 of table N.1
脈沖發生器1950S脈沖波形：10×700μs電壓：0-7KV±5%
